4426100
FUNCTIONS
• RESET (set display to zero)
• mm/inch
• ABS (switch between relative and absolute measurement)
• Lock/Unlock
• PRESET (for entering a numerical value)
• DATA (data transmission via connection cable)
• AUTO-ON / OFF
Application:
• Scribing and marking of work pieces
• Measuring heights and distances
Ask about this product
Description
FEATURES
• Battery life up to 3 years
• Max. measuring speed 1.5 m/s (60”/s)
• MarConnect Data output: choose either
- USB
- OPTO RS232C
- Digimatic
• High contrast liquid crystal display with 12 mm sized digits
• Sturdy heavy-duty base, easy to handle
• Hardened and lapped contact surface which produce both a smooth and even movement
• Slide and beam made of hardened stainless steel
• Hand crank for positioning and measuring
• Fine adjustment
• Locking screw
• Interchangeable scriber point, carbide tipped
• Software: MarCom Professional free download: www.mahr.com/marcom (only for Mahr data cables and wireless systems with USB and RS232 interface)
• Package contains: scriber, battery, carton, instruction manual
